VSG6Plus Valve Seat Guide Machine
9999 INR
Product Details:
- General Use Industrial
- Material Steel
- Computerized No
- Automatic Yes
- Drive Type Electric
- Voltage 440 Volt (v)
- Feature Environmental Friendly
- Click to View more
X
VSG6Plus Valve Seat Guide Machine Price And Quantity
- 1 Unit
- 9999 INR
VSG6Plus Valve Seat Guide Machine Product Specifications
- Industrial
- Steel
- No
- 440 Volt (v)
- 1 Year
- Environmental Friendly
- Electric
- Yes
VSG6Plus Valve Seat Guide Machine Trade Information
- 10 Unit Per Month
- 10 Days
- Wooden Crate Box
- All India
- ISO 9001:2015 CE
Product Description
Main Feature VSG6PLUS
Micron VSG6PLUS Double Air Float Centering System Power Head And Work Head Air Floats Independently to insure Fast And Accurate Guide Centering with Side Hand wheel for spindle downfeed The machine has two modes of operation Side Hand Wheel for Rapid control feed and front Knob wheel for Precise Fine Feed
VSG6PLUS Spindle powered by 1Hp075kW High Torque AC Spindle Motor Frequency Invertor to control spindle torque throughout the speed range 400 Rpm This control gives maximum torque at all speeds resulting in fine surface finish even with the hardest valve seats found in todays EuroBS norms Engines
Micron VSG6PLUS machines are manufactured from heavy thick wall cast iron The all cast iron rigid platform is precision machined providing superior Accuracy as compared to fabricated steel Rigidity is vital in producing Optimum Accurate chatter free valve seat cutting All Cast Parts Are Flame Hardened and Stress Relived which will lead to Repeated Accuracy and Long Last
Three angle single blades insert cuts all three angles at once and produce accurate finished seat with finer Ra Value surface with Leak proof sealing between Valve And valve seat They assure exact seat width from head to head plus concentricity between seat and guide
Spindle Head Tilts to 15 degree on both Sides to accommodate any Guide Axis For Machining of All New Generation Imported and Indian Cylinder Head
Takes Minimum Floor Space to Handle the Complete Range Of Heavy Automotive and Industrial Cylinder Heads
Dial In Variable Spindle Speed 30 to 400 Rpm Without Stopping the Rotation
